Panoramic Glass PVC Dome

$9,950.00

$9,950.00 to $20,600.00 · 18 configurations

Lead time

6 to 10 weeks from order, size dependent. We confirm the date in writing when the order is placed.

Freight

Ships LTL freight to a street address. Liftgate and curbside delivery are included on standard orders. White glove placement is available where the site allows. See Shipping and White Glove for full detail.

Assembly

Ships with drawings and a numbered assembly sequence. Most operators use a local crew. Call us and we will help you scope that work first.

Warranty

The manufacturer's warranty, registered in your name at handover. Terms are stated on the product page before you order.

What this is

Specification and build.

The DSG series puts a double-pane tempered glass bay window across the front of a PVC-covered steel dome. The bay projects, so the glazed area is larger than the dome opening and the view opens sideways as well as forwards.

Six sizes run from 212 to 845 square feet on a truss-jointed reinforced steel frame. The door frame colour is customisable and the glass can be specified clear or frosted.

Sizes

Model	Diameter	Height	Floor area
DSG5300	16 ft	10 ft	212 sq ft
DSG6300	20 ft	12 ft	305 sq ft
DSG7300	23 ft	13 ft	415 sq ft
DSG8300	26 ft	15 ft	541 sq ft
DSG9400	30 ft	15 ft	685 sq ft
DSG1040	33 ft	16 ft	845 sq ft

Construction

Frame	Reinforced steel truss (galvanised steel optional)
Cover	PVC. Flame retardant, waterproof, UV50+
Bay window	Double-pane tempered glass, panoramic
Door	Tempered glass in aluminium frame, clear or frosted, frame colour to order
Colours	White, black, grey

Options

Thermo-insulated liner
Curtain and rod set
Heating: wood stove off-grid, or mini HVAC on-grid
Cooling: mini HVAC

Power and water can run from solar or a generator, or connect to existing supply.

Furniture is not included. Modular toilet, shower and kitchen units are specified separately and are not included in the dome price.

Priced and lead-timed per project. Tell us the size, the finish and the unit count and we will come back with a quote.

Before you order

Do I need a permit?

Often, and the threshold varies by county. Structures over roughly 200 square feet, or anything with plumbing or permanent power, generally require review. We supply engineering drawings and load calculations for your submission.

Before you order

What does the base need?

A level, compacted pad with anchor points. Concrete, timber deck and screw piles are all used. The anchor pattern is in the drawings and depends on the model and your local wind load.

Before you order

Which model fits the site?

Call us with the site dimensions, your winter low and how you plan to use it. We will tell you which models fit and what each one costs delivered. The price on the page is the price you pay, one unit or ten.
